WINDWAY Titanium Frame

Name: WINDWAY Titanium Frame
Brand: Modus Titanium

WINDWAY is a titanium endurance frame with a choice of fork, seatpost and surface finish. Use the model-specific geometry chart to compare your fit, then request a quote for your road build.

700C Frameset | 32C Tire Clearance

View Geometry chart

Size

Seat post

Bike fork

Surface

Add your configuration, then send a quote request from the cart.

Frame specs

Modus 3Al-2.5V titanium frame
Carbon fork
Modus Carbon SL seatpost
Modus Aluminum seatpost collar
Aluminum thru axles
X-12 Drop out with hanger

Technical

Frame Modus 3Al-2.5V titanium frame 1-1/8" to 11/2"; 42/52 BSA-68 Electronic and mechanical compatible 31.8mm front derailleur hanger size Max chainring - 50/34 Shimano Max 700C tire = up to 35c 1650 grams (Size M)

Weight

Rider weight limit = 275 lb / 125 kg Builds typically weigh 16 to 20 lbs depending on groupset, wheel, tire, and component choice.

Warranty

Our frames with 5 years warranty, fork and seat post with 2 years warranty.

Design concept

01Classic & Enduring | Titanium endurance frame built for all-day comfort.

Geometry

Size	48	50	52	54	55	56	58	60	62
Body Height(cm)	<166	166-174	172-180	178-186	184-192	>190
TT Effective length(mm)	495	510	530	545	555	565	575	590	605
Seat tube Length(mm)	450	480	500	520	530	540	550	570	590
Seat tube angle(°)	75	75	74.5	74	73.75	73.5	73	72.75	72.75
Head Tube Length(mm)	100	110	120	130	140	150	160	180	200
Head Tube Angle(°)	71	71.5	72	72.5	72.75	73	73.25	73.5	73.75
BB drop(mm)	74	74	72	72	72	72	72	70	70
Chainstay Length(mm)	415	415	415	415	415	415
Fork Length(mm)	370	370	370	370	370	370
Fork offset(mm)	43	43	43	43	43	43	43	43	43
Fork rake fr(mm)	43	43	43	43	43	43	43	43	43
Reach(mm)	347.7	360.1	372.7	380.2	384.9	389.6	392.1	398.5	407.5
Stack(mm)	535.5	546.8	558.3	569.6	580.1	590.5	599	619	639.1
